Connector Type | SC | FC | ST | LC | ||||
Fiber Type | single mode | multimode | single mode | multimode | single mode | multimode | single mode | multimode |
Insertion loss | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB |
Reflection loss | PC≥45dB UPC≥50dB APC≥60dB |
PC≥25dB UPC≥30dB |
PC≥45dB UPC≥50dB APC≥60dB |
PC≥25dB UPC≥30dB |
PC≥45dB UPC≥50dB APC≥60dB |
PC≥25dB UPC≥30dB |
PC≥45dB UPC≥50dB APC≥60dB |
PC≥25dB UPC≥30dB |
Repeatability | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB |
Interchangeability | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB |
Work Temperature | -40℃~+85℃ |
